Kakati KTC Series Liquid Ring Vacuum Pumps

The two stage vacuum pumps are created for high vacuum applications. As the name suggests they have two stages integrated in one pump. They are designed to operate at very low suction pressures. The integral two stage design allows it to condense process vapors and to recover or dispose of them. This results in a highly reliable and efficient vacuum pump. Some of its main applications include condenser evacuation system and black liquor evaporation.

Basic specification

S.No Specification Description
1 Vacuum range Upto 740 mmHg
2 Capacity Upto 4000 m³/hr ( 2,400 CFM)
3 Standard Construction material Cast iron, Stainless Steel
*Incase of special material of construction please contact our sales team.
